水中油線上感測器 FP360sc Oil-in-Water Sensor, 500 ppb, Stainless Steel Body, 10 m (32.8 ft) Cable, with Cleaning Unit
產品編號：LXV441.99.11202
UV光學法，高精密度，高靈敏度，高效率，運作穩定，線上連續監測水中油
Continuous oil-in-water monitoring for the right price.
即使是最細微的油跡也會損害水質。 高精密型 FP 360 sc 水中油線上感測器專為監測水中的礦物油而設計。 連續監測地面水、製程水和工業水。 浸入式探頭設計。 可選購自動清潔裝置。 每兩年校正一次。 有不銹鋼或鈦材質可供選擇。
Even the smallest oil traces can impair water quality. The FP 360 sc is specifically designed to detect traces of mineral oils in water while providing the necessary value and benefits for a positive return on investment. The sensor monitors surface water, process water and industrial water continuously. It has a submersible probe design. The sensor comes with an optional cleaning unit. Calibrate once every two years. Available in stainless steel or titanium.
Measurement Method 量測方法 : UV fluorescence method for polycyclic aromatic hydrocarbons (PAH) 多環芳烴（PAH）的紫外線光學法
Range 量測範圍 : 0 - 500 ppb (µg/L) (PAH) or 0.1 - 15 ppm (mg/L) (Oil)
Detector 偵測器 : UV photodiode with interference filter; Compensation of daylight and flashlamp intensity fluctuations
Excitation : Wavelength 254 nm
*使用Hach SC系列 digital controllers 數位水質控制主機進行監控
關鍵字 : 連續監測 水中 油 線上分析儀, 精密型 水中油 線上監測儀, oil in water analyzer, monitor oil in water
Continuous oil-in-water monitoring for the right price.
即使是最細微的油跡也會損害水質。 高精密型 FP 360 sc 水中油線上感測器專為監測水中的礦物油而設計。 連續監測地面水、製程水和工業水。 浸入式探頭設計。 可選購自動清潔裝置。 每兩年校正一次。 有不銹鋼或鈦材質可供選擇。
Even the smallest oil traces can impair water quality. The FP 360 sc is specifically designed to detect traces of mineral oils in water while providing the necessary value and benefits for a positive return on investment. The sensor monitors surface water, process water and industrial water continuously. It has a submersible probe design. The sensor comes with an optional cleaning unit. Calibrate once every two years. Available in stainless steel or titanium.
Measurement Method 量測方法 : UV fluorescence method for polycyclic aromatic hydrocarbons (PAH) 多環芳烴（PAH）的紫外線光學法
Range 量測範圍 : 0 - 500 ppb (µg/L) (PAH) or 0.1 - 15 ppm (mg/L) (Oil)
Detector 偵測器 : UV photodiode with interference filter; Compensation of daylight and flashlamp intensity fluctuations
Excitation : Wavelength 254 nm
*使用Hach SC系列 digital controllers 數位水質控制主機進行監控
關鍵字 : 連續監測 水中 油 線上分析儀, 精密型 水中油 線上監測儀, oil in water analyzer, monitor oil in water
Lowest Cost of Ownership
The FP 360 sc is specifically designed to detect traces of mineral oils in water while providing the necessary value and benefits for a positive return on investment.
The FP 360 sc is specifically designed to detect traces of mineral oils in water while providing the necessary value and benefits for a positive return on investment.
The Right Technology for the Right Price
Due to its unique combination of submersible probe design and UV fluorescence sensing technology, the FP 360 sc delivers the best technology to detect oil in water and is priced below competitive UV fluorescent instruments.
Due to its unique combination of submersible probe design and UV fluorescence sensing technology, the FP 360 sc delivers the best technology to detect oil in water and is priced below competitive UV fluorescent instruments.
Minimal Maintenance
The FP 360 sc has no tubes, pumps, or valves that can foul or require constant maintenance interventions. Maintenance is limited to occasional wiping of the sensor's measurement window, calibration once every two years, and Xenon lamp replacement every four years.
The FP 360 sc has no tubes, pumps, or valves that can foul or require constant maintenance interventions. Maintenance is limited to occasional wiping of the sensor's measurement window, calibration once every two years, and Xenon lamp replacement every four years.
Reduced Laboratory Testing
While laboratory testing is the ultimate method of measuring oil in water, it is a long and complex process that requires special equipment and trained lab personnel. The FP 360 sc provides a cost-effective, continuous online monitoring solution to maintain process control and avoid oil contamination with minimal laboratory testing.
While laboratory testing is the ultimate method of measuring oil in water, it is a long and complex process that requires special equipment and trained lab personnel. The FP 360 sc provides a cost-effective, continuous online monitoring solution to maintain process control and avoid oil contamination with minimal laboratory testing.
High Sensitivity and Selectivity
The FP 360 sc can detect and measure polycyclic aromatic hydrocarbons (PAHs) from 1.2 ppb to up to 5000 ppb (µg/L). This is approximately equivalent to a concentration of mineral oil between 0.1 to 150 ppm (mg/L). Furthermore, the FP 360 sc method of detection makes it impervious to interferences by turbid water or natural organic and biological matter that impact online light scattering, UV absorbance, and VIS fluorescence instruments.
The FP 360 sc can detect and measure polycyclic aromatic hydrocarbons (PAHs) from 1.2 ppb to up to 5000 ppb (µg/L). This is approximately equivalent to a concentration of mineral oil between 0.1 to 150 ppm (mg/L). Furthermore, the FP 360 sc method of detection makes it impervious to interferences by turbid water or natural organic and biological matter that impact online light scattering, UV absorbance, and VIS fluorescence instruments.
Available in stainless steel or titanium housing for measurement in the harshest of conditions
